Overview
This swivel and tilting wall mount bracket is designed to hold most 23 inch to 42 inch flat screen displays with a maximum VESA hole pattern of 200x200. It offers a up to a +10° to -3° tilt and a +15° to -15° swivel. It can be used in both residential and commercial environments.
|
Full Motion Makes any Seat, the Best SeatThe tilt and swivel motion of the mount allows you to position your TV to the best viewing angle, and provide the maximum viewing experience. Level Adjustment is Easy on the EyesThe built-in level adjustment ensures perfect positioning for a pleasurable viewing experience.
|
Specifications
| Physical Characteristics | |
|---|---|
| Mounting Style | Tilting & Swivel Wall Mount |
| Color | Black |
| Material | Steel, Plastic |
| Mounting Pattern | VESA 100x100, 200x100, 200x200 |
| Screen Size | 23 - 42 inches [58 - 107cm] |
| Weight Capacity | 66lbs [30kg] |
| Tilt | +3° ~ -10° |
| Swivel | +15° ~ -15° |
| Profile | 75mm |
| Level Adjustment | -3° ~ +3° |
| Installation | Single Stud |
| Approvals | |
| RoHS | Yes |
| Reach | Yes |
| Packaging Information | |
| Package Quantity | 1 |
| Mounting Hardware | 4 - M4x14 Screws 4 - M5x14 Screws 4 - M6x14 Screws 4 - M8x20 Screws 4 - D5 Washers 4 - D8 Washers 8 - Small Spacers 3 - ST6.3x55 Screws 3 - Concrete Anchors 3 - D6 Washers |
| Product Weight | 3.3lbs [1.5kg] |
| Warranty Information | |
| Warranty |
Limited Lifetime |
5-YEAR LIMITED LIFETIME WARRANTY
Infinite Cables Inc. offers a 5-year warranty on all TV mounts to be free from defects in material and workmanship.
This warranty is available to the original purchaser with proof of purchase. This warranty does not apply to any damage or product failure that is caused beyond Infinite Cables’ control, including but not limited to, misuse, neglect, accidental damage, improper installation or application, alteration, acts of God, or normal wear and tear. Infinite Cables is not responsible for any costs of removal or installation. Infinite Cables’ sole and exclusive obligation under this warranty shall be limited to repair or replacement of the defective item at our discretion.
Infinite Cables makes no other warranties expressed or implied including without limitation and warranty of fitness for a particular purpose. Infinite Cables will not be liable for damages of any kind including lost or anticipated profits, delay, consequential or special damages.
| SKU | Weight | |
| MT-540-BK | 2.65 lb |
